YZYX10J-2 Screw Oil Press

YZYX10J-2 Screw Oil Press

The YZYX10J-2 is a newly designed 4 steps squeeze oil press with longer squeeze cage than normal YZYX10series. The pressing force in the chamber is bigger which can provide the press result and oil yield efficiency are better, for obtaining bigger profit.
  • Product Description

  • Video

Main equipment parameters of YZYX10J-2 Screw Oil Press

Model Processing Capacity(T/24H) Motor Power(KW) Oil Content of Dry Cakes(%) Spiral Axes Rotate Speed(r/min) Measurement(L*W*H)(mm) Weight(kg)
YZYX10J-2 4.5 11 ≤6.0 26-41 1720*580*1185 590

Note:

This weight has no electro-motors' weight.
The series YZYX10 spiral oil press produced by our company is suitable for squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flax seed, tung oilseed, sunflower seed, palm kernel, etc. The product has characteristics of the small investment, high capacity, strong compatibility, and high efficiency. It is widely used in the small oil refinery and rural enterprise.

The YZYX10J-2 are 4 steps squeezing spiral oil presses newly developed by our company. Their pressing force in the chamber is bigger than that of 3 steps squeezing model. Practices proved that the press result and oil yield efficiency are better when properly process the oil plants which have been pretreated well. They are suitable for users with operation experience and stress on low oil content in the cake. Users could obtain a bigger profit.

Main Features of YZYX10J-2 Screw Oil Press

Below features are based on oil plants above the average quality smoothly and continuously squeezed after such pretreatments as screening, husking, flaking and cooking, etc.

Oil Plants Processing Capacity (t/24h) Oil content of
Dry cakes (%)
Oil yield Efficiency (%) Electricity
Consumption (k.W.h/t)
Rapeseed ≥4.5 ≤8.0 ≥80 ≤35
Cotton seeds ≥4.5 ≤7.5 ≥75 ≤55
Soybean ≥3.8 ≤7.0 ≥65 ≤52
Peanut ≥4.5 ≤8.0 ≥91 ≤35

The product conforms to the "Technology Standard of Agricultural Spiral Oil Press" under JB/T9793-2013 of the People's Republic of China.

Maintanence of Oil Press



Oil Press Operation
