YZYX140 Screw Oil Press

YZYX140 Screw Oil Press

YZYX140 series is commonly using the oil processing workshop and big oil mill factory, can be set for 10 ton to 100 TPD oil mill factory. This series has multiple models for various needs: such as YZYX140CJ with longer squeeze cage, YZYX140GX with enhanced big gearbox.
  • Product Description

  • Video

YZYX140 Screw Oil Press has the models as below:

Item YZYX140 YZYX140GX YZYX140CJ YZYX140CJGX
Processing Capacity(t/24h) 9-11 9-11 9-11 9-11
Oil Content of Dry Cakes(%) ≤7.6 ≤7.6 ≤7.6 ≤7.6
Motor Power(kW) 18.5 or 22 18.5 or 22 18.5 or 22 22
Weight(kg) 806 1000 884 1100
Measurement(L*W*H)(mm) 2010*690*1430 2150*820*1370 2100*690*1400 2300*820*1370
Spiral axes rotate(r/min)
28-38 30-40 28-38 30-40

Note:

This weight is without electro-motors' weight.
① It is normal that sometimes the actual results may be a little different from those in the index because the oil plant’s type, quality, and original content may be different in different areas.
② The day capacity (t/24h) is based on using hot way to squeeze one time. The more the squeeze times are, the lower the date capacity is.

Our series YZYX140 spiral oil press is suitable for squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flax seed, tung oil seed, sunflower seed, and palm kernel, etc. The product has characters of small investment, high capacity, strong compatibility, and high efficiency. It is widely used in the small oil refinery and rural enterprise.

YZYX140 is basic 2-step-squeezing spiral oil press.
YZYX140-8 is 3-step squeezing spiral oil press with the bigger compression ratio in the press chest, suitable for users who have operation experience and stress on the low oil content of the dry cakes.
YZYX140GX is developed on the base of normal 140 series oil press. It is with enhanced beveled gears, running more stable, more wearable and the noise is lower.
YZYX140CJ is a strong pressing type in which the pressure is big. Thus, the squeezing effect is better when operates properly.
YZYX140CJGX has enhanced gearbox with bigger beveled gears, running more stable, more wearable and the noise is lower. In the meanwhile, the press cage is longer, and oil yield is higher.

Main Features of YZYX140 Screw Oil Press

Below features are based on oil plants above the average quality smoothly and continuously squeezed after such pretreatments as screening, husking, flaking, and cooking, etc.

Oil Plants Oil content of Dry cakes (%) Oil yield
Efficiency (%)
Electricity Consumption
(k.W.h/t)
Rapeseed ≤7.6 ≥88 ≤35
Cotton seeds ≤6.5 ≥78 ≤55
Soybean ≤6.6 ≥76 ≤52
Peanut ≤7.0 ≥92 ≤35

The product conforms to the "Technology Standard of Agricultural Spiral Oil Press" under JB/T9793-2013 of the People's Republic of China.

Maintanence of Oil Press



Oil Press Operation
